Open Type Welder Diesel Generator | ||
Generator | Model | SDG6500EW |
Rated Output(KVA) | 4.6/5.0 | |
Max Output(KVA) | 5.0/5.5 | |
Rated Frequency(Hz) | 50/60 | |
Rated AC Voltage(V) | 110/220, 120/240, 220/380, 240/400 | |
DC Outpu(V) | 12V/8.3A | |
Power Factor(cosθ) | 1/0.8(Three Phase) | |
Phase | Single or Three Phase | |
Starting System | Electric Starter | |
Noise Level(Dba/7m) | 68-72 | |
Fuel Tank Capacity(L) | 16 | |
Continuous Running Time(Hr) | 8.5/7.8 | |
Engine | Model | SE186FAE |
Power(HP) | 6.3 | |
Engine Type | Air-Cooled; Single-Cylinder; 4-Stroke; OHV | |
Fuel Type | 0#(Summer), -10#(Winter)Diesel Oil | |
Displacement(cc) | 418 | |
Min Fuel Consumption(g/kw/h) | 280 | |
Lube Oil Capacity(L) | 1.65 | |
WELDER | Welding no-load voltage(V) | 55-65 |
Working voltage(V) | 26-30 | |
Rated current(A) | 160 | |
Range of current(A) | 20-190 | |
Welding efficiency | 0.6 | |
Dimension & Packing | Dimension(L*W*H)(mm) | 910*530*740 |
Net Weight(kg) | 150 | |
Packing | In Strong Corrugated Board Carton | |
20FT Loading Quantity | 144 | |
40HQ Loading Quantity | 288 | |
Payment | Payment Terms | T/T or L/C |
Minimum Order Quantity | 5 PCS | |
Delivery Lead Time | Within 15days after received the deposite | |
Warranty | One Year or 500 Working Hours | |
1.Modern workshops have advanced production lines with whole set of inspection, testing equipment. 2.Skilled assemblers is vital to promise high quality production.
3.Flow card to record each details carefully.
4.Test engine at least 45mins to adjust the best state.
1. We are factory of manufacturing diesel and gasoline engine,diesel generator from 2-1000KW,water
pump,trash pump,construction machinery like vibrator,rammer,compactor,concrete cutter,power
trowel, agriculture machinery and so on.
2. Modern workshop and production line, we warmly welcome your visiting.
3. We attend exhibitions domestic and overseas. Rich activities to improve work enthusiasm.
4. ISO,CE,GS,Rohs certificates.We have been making good progress.
ISO9001-2008, CE
1. Q: What is your MOQ of this item?
A: 1 set.
2. Q:Are you a factory or Trading company?
A: We are a professional manufacturer.
3. Q:Is it alright to make customer’s own brand name?
A: Sure,as long as you authorize us to use your brand on your behalf.
4. Q:What are your payment terms?
A: T/T 30% deposit, 70% balance should be paid against the B/L copy.
D/P for regular good reputation customers.
Paypal is accepted for one set, but please discuss to our sales people first.
5. Q:how long is your warranty?
A: 1years or 500hours warranty, whichever comes first except the wearing and tearing parts.
We suggest customers buy some wearing and tearing parts in each order.
6. Q:What is the delivery time?
A: 20 days after receiving advance payment.
If the items which you purchase is om stock we can send them out immediately.
7. Q: What is your company production capacity?
A: 5000 sets per month.
8. Q: Is the engine customized?
A:Yes. Engines can be customized according to customers’ design.
